The P470 is powered by Intel® Centrino® Mobile Technology, Core™ Duo processor and a dedicated graphics processor that you can have the best wireless access and performance in various applications. P470 is equipped with 14.1” wide daylight readable touch screen which offers readability to outdoor situations as well as indoors. WLAN can be instantly switched to a built-in 3G communication solution to maintain accessibility to networks without adding any extension modules. In the tough environments security always matters, the P470 has a built-in TPM 1.2 module, finger print scanner and Smart Card reader to provide additional 3 layers of excellent protection for valuable data. The magnesium alloy case, shock-mounted hard drive, and spill-resistant keyboard allow P470 to be able to adapt to daily environments.
|
- Magnesium Alloy Case
- Sealed Ports and Connectors
- Shock-mounted Removable HDD
- Vibration & Drop-shock Resistant
- Water and Dust Resistant
- Sunlight-readable LCD Screen
- Versatile Wireless Access: WLAN, WWAN and Bluetooth
- Media-Bay Features Maximizes Flexibility and Customized Applications
|
Specification |
| Ruggedness |
Rugged
Magnesium alloy case
Sealed ports and connectors
Shock-mounted removable HDD
Vibration & drop-shock resistant |
|
|
| CPU |
Intel Core2 Duo T7400 2.13GHz processor
667 MHz FSB
4MB L2 cache |
|
|
| Memory |
512MB DDR2 expandable to 4GB |
|
|
| VGA Controller |
Intel® 945GM
(Reserved for Discreted VGA: Mobility Radeon X1450 with 256mb VRAM) |
|
|
| Storage |
SATA 80GB expandable to 160GB |
|
|
Display
|
14.1" WXGA (1280x800) TFT LCD
Optional touch screen
Optional sunlight readable LCD screen |
|
|
Communication Interface
|
10/100/1000 base-T Ethernet
56K ITU V.92 modem
IntelR PRO/Wireless 802.11 a/b/g (Reserved for 802.11n)
Optional GPS (with integrated antenna)
Optional Bluetooth 2.4G (v2.0 class 2)
Optional 3G WWAN Module |
|
|
| I/O Interface |
Serial Port x 1
USB 2.0 x 3
External VGA x 1
1394B x 1
Parallel port x 1
RJ-45 x 1
RJ-11 x 1
Microphone x 1
Line out x 1
DC in x 1
Docking port x 1 (54 pins) + 3 RF |
|
|
Expansion Slots
|
Type II x 1
Multi card reader x 1
Express card 54mm X 1 |
|
|
Media Bay
|
Combo
Optional DVD Dual
Optional 2nd battery
Optional 2nd HDD 80/120 GB (IDE TYPE)
Optional additional IO ports |
|
|
| Power Supply |
Adapter (90W, 100-240V, 50/60Hz)
Li-Ion Smart Battery (4800mAh)
Optional Media Bay 2nd Li-Ion battery (3700mAh) |
|
|
| Operating System |
Microsoft® Windows® XP Professional |
|
|
| Security Features |
TPM 1.2
Kensington lock
Finger print scanner
Smart Card reader |
|
|
| Dimensions & Weight |
333 x 295 x 42 mm (13.1" x 11.6" x 1.6"), 2.95 kg (6.5 lbs) |
|
|
| Other |
CMOS 1.3 Mega Pixels
Projected LED Light for keyboard |
|
|
|
|
|
| Environmental Test Specifications |
|
| Item |
Test Criteria |
| Temperature |
• Operating: 0°C (32°F) to 45°C (131°F)
• Non-operating: -40°C (-40°F) to 70°C (158°F) |
| Humidity |
According to IEC 68-2-30 / MIL-STD-810F, Method 507
45% to 95% RH, non-condensing |
| Altitude |
According to IEC 68-2-13/ MIL-STD-810F, Method 500.4
• Operating: 15,000ft
• Non-operating: 40,000ft
• Altitude change rate: 2,000ft/min |
| Shock |
According to IEC 68-2-27/ MIL-STD-810F, Method 516.5 |
| Drop |
76cm (3 feet) height free drop (73.7cm from wood) |
| Vibration |
According to IEC 68-2-6 / MIL-STD-810F, Method 514.5 |
| ESD |
Air Discharge: 8kV~15kV
Contact Discharge 4kV~8kV: |
| Regulation |
FCC, , CE, CB, WHQL, |
|
|
|
 |
|
|
|
|
|
|
|
