| System Specifications |
| Processor: |
 Intel® Pineview-M CPU N450 1.6 GHz, FSB 667MHz |
| Operating System: |
Microsoft Windows® XP Tablet Edition
Microsoft Windows Vista® Business
Microsoft Windows® 7 professional |
| Memory: |
SO-DIMM Socket for 2GB RAM Module |
| Chipset: |
ICH8-M |
| Storage: |
1.8” SATA HDD (5mm thickness)Optional SATA SSD |
| Display: |
10.4” XGA (1024x768) LED backlight TFT LCD with touch screen panel (Optional Sunlight readable solution) |
| Audio: |
HD Audio
One sealed speaker nominal power: 2W
Mic. Array for VOIP |
| Webcam: |
2 mega pixels resolution webcam |
| I/O Ports: |
DC-in with rubber plug
Docking connector(contact pin type) |
| Wireless / Communications: |
One Express mini card for WLAN support CCX function (roaming)
WLAN card support IEEE 802.11 b/g/n with 1x2 MIMO
Internal Bluetooth module and Internal 3G module(option) |
| Battery: |
Battery pack: Hot Swappable twin battery packs(total 53.28Watt) |
| AC Adapter: |
AC power input:100V-240V,50Hz-60Hz, 65W, Output: 19V |
| Dimensions & Weight: |
260mm(W) x 263mm(D) x30~33.2mm(H) / 10.23”(W) x 10”(D) x 1.18”(H)
Approximately 1.32Kg / 2.9lbs with one 3cell battery |
| Integrated options: |
RFID reader support ISO 14443A/B and 15693
1D/2D Barcode scanner with red ray scanning |
| Certification: |
CUL,FCC,CE!,CB,FCC ID,IC,TUV-GS(TBD) |
| Security: |
Administrator password and Boot password
TPM1.2
Finger Print Scanner(factory option) |
| Optional Docking Station: |
Host slot x1, USB 2.0 x 4, Power cord connector x 1, Battery charging bay x 2,
RJ-45 jack for 10/100M Ethernet LAN x 1 |
