| Rugged Design |
 Drop Resistant:
Aluminum-Magnesium Alloy Top and Bottom Case / 20x Stronger than ABS plastic
Shock Resistant:
Rubber-Mounted LCD Screen and Hard Disk Drive
Spill Resistant:
Spill Resistant Keyboard, Fully Insulated Touchpad Area, and Spill Tray
Dust Resistance:
MIL-STD-810F 510.4 Procedure I and IP-54 Compliant
Optical Disk Lock:
Prevents Unintentional Tray Ejection
Battery Protection:
Double Protection Smart Battery Circuitry Prevents Damage Caused by Electric Current or Voltage Surges and Overheating. Smart Battery Calibration Helps Fight the Loss of Battery Capacity After Repeated Charge/Discharge Cycles
Rugged Benefits:
Provides Added Protection to the Vital Components from Drops, Shocks, Bumps, Concussions, Spills, and Other Accidents. Helps Prevent Damage, Data Loss, and Costly Repairs |
| Display |
13.3" WXGA Convertible Touch Screen and Sunlight Readable LCD |
| Technology |
Intel® Core 2 Duo (Merom, Ultra Low Voltage) U7500 Technology |
| CPU Processor |
Intel® Core 2 Duo (U7500) 1.06GHz Processor |
| Hard Disk Drive |
160GB upgradeable 250GB SATA Hard Disk Drive
5400rpm upgradeable 7200rpm Hard Disk Drive |
| Memory |
2GB DDRII, upgradeable to 3GB or 4GB DDRII |
| Wireless LAN / LAN |
Modem: Internal 56K V.90 Fax/Modem
Intel® Pro-Wireless 802.11 a/g/nLAN,
Integrated 10/100/1000Mbps Ethernet
Optional Bluetooth |
| Operating System |
Microsoft® Windows® Vista® Business
Microsoft Windows® 7 Professional
Microsoft Windows® XP Tablet PC Edition |
| VGA |
Intel® GME965 Integrated Graphics |
| Optical Drive |
Ultra-Slim SATA Super-Multi DVD Burner |
| Audio |
HD Audio
Built-in speaker x 2 (Total Max: 4W)
Microphone x 2 (array microphone) |
| I/O Devices |
Water-Proof Resistive Touchpad
86 key LED Back Light keyboard, IP54 Compliant |
| I/O Ports |
1 x LAN RJ45 10/100/1000 / 1 x DC -in / 1 x Docking Connecter / 1 x VGA / 3 x USB 2.0 ports / 1 x SIM Card Connector / 1 x RS -232 / 1 x Ear Phone-out Jack / 1 x PC Card Slot / 1 x Smart Card Reader / 1 x MIC-in Jack / 1 x SD Card Reader |
| Wireless / Communications |
Intel® 4965 802.11 a/g/n
WWAN : HSDPA/GPRS/GSM/WCDMA (option)
GPS Receiver Support
PAN:Bluetooth 2.0 + EDR Class 1 |
| Power |
AC/DC adapter : Input: AC 100~240V 50/60Hz, universal Output: 19V DC, 4.74A, 90W
9-cell Smart Lithium-Ion Battery Pack
|
| Temperature |
High Temp: According to MIL-STD-810F 501.4 Procedures I (Storage) and II (Operation)
Low Temp: According to MIL-STD-810F 502.4 Procedures I (Storage) and II, IIl (Operation)
Operating: Standard -4˚F to 122˚F
Non Operating: -4°F to 158°F |
| Humidity |
According to MIL-STD-810F 507.4 Procedures I (Storage) and II (Operation) |
| Altitude |
According to MIL-STD-810F 500.4 Procedures I (Storage) and II (Operation) |
| Security |
TPM1.2 (Trusted Platform Module Security Chip)
BIOS setup, Power-on, HDD User Password Protection
Fingerprint Recognition, Kensington Lock |
| Dimensions & Weight |
344mm(W) x 253mm(D) x 58mm(H) / 13.54’’(W) x 9.96’’(D) x 2.84’’(H)
Weight<4.1Kg / 9.04lbs |
| Agency EMI / Safety |
EMI: FCC, CE, MIL STD 461E Safety : CB, cUL, UL |
|
| MIL STD 810F |
| LCD Cover Pressure Test |
Withstand 15kg pressure from 6x10cm cubic, 3cm and 10cm diameter column, and 6kg pressure from 1.2cm diameter column. |
| Magnesium Alloy Case |
Base & LCD Cover (Forms solid magnesium box when LCD cover is closed.)
Magnesium Alloy is 20 times stronger than ABS plastic |
| HDD Shock Absorber |
Yes |
| LCD Shock Absorber |
Yes |
| Water Resistant Keyboard |
Yes |
| Spill Resistant Touch Pad, Buttons, LED |
Yes |
| Protection from Solid Object |
2.5mm and greater |
| Protection from Water |
Vertical water drops |
| Drop Protection Test |
29” Height
Military Standard 810F, Method 516.5 Procedure IV, drop 6 faces, 8 corners, and 12 edges, total 26 drops. |
| Protection from Mishandling the System on a Table |
Yes
Operating Mode: Tilt one edge up 7cm and drop 25 times. 4 edges total 100 times. Non-operating Mode: Tilt one edge up 10cm and drop 25 times. 4 edges total 100 times. |
| Vibration Protection |
Yes
Military Standard 810F, Method 514.5 Procedure I, Simulating 1,000 miles of truck transportation. |
